LeeBoy 685D - Page 237

Moldboard Turntable Assembly, 11 Ft/12 Ft (4 of 4)
Item
No
Part Number Qty Description Remarks
1 1018110 1 Moldboard Assembly, 11 Ft. x 21" Includes Items 2-6
2 1011670 1 Moldboard Cutting Edge, 11 Ft.
3 130180 4 Moldboard Curved End Bit
4 130220 A/R Plow Bolt, 5/8-11 x 2.00
5 302-10 A/R Washer, Lock, 5/8
6 200-10-11-5 A/R Nut, Hex, 5/8-11, GR5
7 1018442 1 OPTION - Moldboard Assembly, 12 Ft. x 21" Includes Items 3-6,8
8 853860 2 Moldboard Cutting Edge, 6 Ft., Offset Punched
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-29
