Controls - 10 Station (1 of 3)
Item
No
Part Number Qty Description Remarks
GRP 1018087 1 Group - 10 Station Console
1 1018088 1 Console
2 1018090 1 Console Face Panel
REF 1018429 1 Steering Motor Assembly w/Fittings Includes Items 3-5
3 100397 1 Steering Control Unit
4 FS6801-08-08-NWO-FG 2 Elbow Adapter, 90°, -8 ORFS/-8 O-Ring
5 FS6400-08-08-O 2 Straight Adapter, -8 ORFS/-8 O-Ring
6 300040 1 Steering Column, 6.00"
7 115772 1 Steering Wheel, 14.00"
8 300020 1 Nut, Hex, 13/16-20
9 20944062 1 Steering Wheel Cap
10 31985 2 Dash Light - Green
11 1010500 1 Dash Light - White
12 31986 1 Dash Light - Blue
13 31983 1 Dash Light - Red
14a 35136-4 2 Hole Plug, Flush Mount - 1/2" 2WD Option Only
14b 1001625 1 Dash Light - Amber AWD Option Only
15 1018803 1 PV480 Display (w/o throttle)
16 1018628-03 1 Decal - Front Control Panel
17 100-5-18-16-5F 4 CSHH, 5/16-18 x 1.00, GR5, FT
18 302-5 4 Washer, Lock, 5/16
19 300-5 4 Washer, Flat, SAE, 5/16
20 100-6-16-24-5 4 CSHH, 3/8-16 x 1.50, GR5
21 302-6 4 Washer, Lock, 3/8
22 33687 1 Turn Signal w/Hazard
23 1018628-04 1 Decal - Info, Lube Chart
