LeeBoy 685D - Page 261

Item
No
Part Number Qty Description Remarks
REF 1018235 1 Control Panel Assembly
1 1010794 1 Cup Holder
2 1018628-01 1 Decal - Control Panel, Top
3 851090624 3 Toggle Switch, SPDT, 2-POS
4 1010672 1 Emergency Stop Switch, 1-NC
5 1010692 1 Contact Block, 1-NC
6 1018628-02 1 Decal - Control Panel, Front
7 73119-CMG 2 Switch - Wiper/Washer
8 35136-20 1 Hole Plug, .562
9 1018390 1 Toggle Switch, DPDT, 3-POS
10 851090613 1 Toggle Switch, SPDT, 3-POS
11 851391 5 Toggle Switch, SPST, 2-POS
12 72086 2 Toggle Switch, DPST, 2-POS
13 982249 1 Push Button Switch
14 39146-14 1 Ignition Switch
15 35812 1 Lock w/Offset Cam
16 1011147 1 12V Receptacle
17 1018628-05 1 Decal - Fuse Panel
18 685060 1 Fuse Block, 18 Gang, ATC
19 36340 16 Fuse, 10A, ATC
20 36341 3 Fuse, 15A, ATC
21 36695 1 Fuse Block, 6 Gang, ATC
22 36085 5 Relay, 12VDC, SPDT, 40A, 5-PIN
23 851091608 1 Signal Flasher
24 36086 6 Relay Mounting Bracket
25 720290 1 Solenoid, 12V, Constant Duty
26 1019586 1 Resistor, 68 Ohm, 25 Watt
Controls - Panel
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-53
