Hydraulics - 2WD
Item
No
Part Number Qty Description Remarks
REF 1019747 1 Articulation Valve Assembly w/Adapters Includes Items 1-3
1 1019746 1 Articulation Lock Check Valve
2
FS6803-06-06-06-NWO-FG
2 Branch Tee Adapter, -6 ORFS/-6 ORFS/-6 O-Ring
3 FS6400-06-06-O X 100 2 Straight Adapter, -6 ORFS/-6 O-Ring, .100 Orice
REF 1019684 1 Moldboard Manifold Assembly w/Adapters Includes Items 4-5
4 1019696 1 Moldboard Slide Manifold
5 FS6400-06-06-O 6 Straight Adapter, -6 ORFS/-6 O-Ring
REF 1018641 1 Moldboard Cushion Valve Assembly w/Adapters Includes Items 5-7
6 122084 1 Circle Turn Cushion Valve
7 FS6801-06-06-NWO-FG 2 Elbow Adapter, 90°, -6 ORFS/-6 O-Ring
REF 1018364 2 Cover Plate Assembly w/Adapters Includes Items 8-16
8 1018223 2 Cover Plate
9 1018392 2 Connector, 6-Pin, DT04-6P-L012
10 FS0304-C-06 2 Cap Adapter, -6 ORFS
11 FS2700-06-06 2 Bulkhead Union Adapter, -6 ORFS/-6 ORFS
12 FS0306-06 2 Bulkhead Lock Nut, -6 ORFS
13 122-#8-32-12F 8 PHMS, Cross, #8-32 x .75, FT
14 300-#8 8 Washer, Flat, #8
15 302-#8 8 Washer, Lock, #8
16 209-#8-32 8 Nut, Hex, Machine Screw, #8-32
17 100-4-20-16-5 8 CSHH, 1/4-20 x 1.00, GR5
18 302-4 14 Washer, Lock, 1/4
19 300-4 18 Washer, Flat, SAE, 1/4
20 100-4-20-32-5 2 CSHH, 1/4-20 x 2.00, GR5
21 200-4-20-5 6 Nut, Hex, 1/4-20, GR5
22 100-4-20-36-5 2 CSHH, 1/4-20 x 2.25, GR5
23 100-4-20-40-5 2 CSHH, 1/4-20 x 2.50, GR5
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-61
