Hydraulics - Brake, 2WD/AWD
Item
No
Part Number Qty Description Remarks
REF 1018340 1 Brake System Assembly w/Adapters
1 1017529 1 Charge Valve Weldment
2 852720 1 Low Pressure Brake Switch
3 FS6400-04-04-O 1 Straight Adapter, -4 ORFS/-4 O-Ring
4 750602 1 Brake Manifold w/Relief
5 FS6802-08-12-NWO-FG 1 Elbow Adapter, 45°, -8 ORFS/-12 O-Ring
6 6408-8-O 1 Plug Adapter, -8 O-Ring
7 FS6801-08-08-NWO-FG 3 Elbow Adapter, 90°, -8 ORFS/-8 O-Ring
8 FS6400-08-08-O 1 Straight Adapter, -8 ORFS/-8 O-Ring
9 852740 1 Brake Charge Valve
10 FS6400-08-12-O 1 Straight Adapter, -8 ORFS/-12 O-Ring
11 FS6801-08-12-NWO-FG 1 Elbow Adapter, 90°, -8 ORFS/-12 O-Ring
12 1010390 1 Brake System Accumulator, 60 CI
13 FS6540-08-08-O 1 Swivel Straight Adapter, -8 ORFS/-8 O-Ring
14
FS6804-08-08-08-NWO-FG
1 Run Tee Adapter, -8 ORFS/-8 O-Ring/-8 ORFS
15 FS6602-06-08-06-FG 1 Swivel Run Tee Adapter, -6 ORFS/-8 ORFS/-6 ORFS
16 FS6500-06-06-FG 1 Swivel Elbow Adapter, 90°, -6 ORFS/-6 ORFS
17 FS2406-06-04 1 Straight Reducer Adapter, -6 FFORX/-4 ORFS
18 100-6-16-20-5 3 CSHH, 3/8-16 x 1.25, GR5
19 302-6 5 Washer, Lock, 3/8
20 300-6 7 Washer, Flat, SAE, 3/8
21 100-4-20-36-5 1 CSHH, 1/4-20 x 2.25, GR5
22 302-4 2 Washer, Lock, 1/4
23 100-4-20-60-5 1 CSHH, 1/4-20 x 3.75, GR5
24 100-6-16-28-5 2 CSHH, 3/8-16 x 1.75, GR5
25 200-6-16-5 2 Nut, Hex, 3/8-16, GR5
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-63
