LeeBoy 685D - Page 279

Hydraulics - Pumps, AWD (Cont.)
Item
No
Part Number Qty Description Remarks
42 FS6801-08-10-NWO-FG 2 Elbow Adapter, 90°, -8 ORFS/-10 O-Ring
43 FS6602-08-08-08-FG 2 Swivel Run Tee Adapter, -08 ORFS (x3)
44 FS2406-08-04 2 Straight Reducer Adapter, -8 FFORX/-4 ORFS
45 FS6801-24-20-NWO-FG 1 Elbow Adapter, 90°, -24 ORFS/-20 O-Ring
46 100-8-13-24-5F 2 CSHH, 1/2-13 x 1.50, GR5, FT
47 309-8-20-3 2 Washer, Thick, 1/2 x 1.25 x .188
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-71
