LeeBoy 685D - Page 293

Engine - Battery Box
Item
No
Part Number Qty Description Remarks
1 1018070 1 Battery Box
2 35812 1 Door Lock
3 1020571 1 Prop Rod Bar
4 100-4-20-16-5 1 CSHH, 1/4-20 x 1.00, GR5
5 300-4 2 Washer, Flat, SAE, 1/4
6 205-4-20-5 1 Nut, Lock, Nylon, 1/4-20, GR5
7 100-8-13-24-5F 2 CSHH, 1/2-13 x 1.50, GR5, FT
8 302-8 2 Washer, Lock, 1/2
9 300-8 2 Washer, Flat, SAE, 1/2
10 982962 1 Battery Hold-down Assembly
11 36688-55 2 Knob
12 122-#10-24-12F 2 PHMS, Cross, #10-24 x .75, FT
13 300-#10 4 Washer, Flat, SAE, #10
14 302-#10 2 Washer, Lock, #10
15 209-#10-24 2 Nut, Hex, Machine, #10-24
16 100-6-16-152-5 2 CSHH, 3/8-16 x 9.50, GR5
17 302-6 2 Washer, Lock, 3/8
18 300-6 2 Washer, Flat, SAE, 3/8
19 Purchase Locally 2 Battery, 12VDC, 800CCA, Group 24
20 109740 1 Battery Master Disconnect Switch
21 1019672 1 Battery Cable (-), 28", Eye/Eye, 4 AWG
22 1019673 1 Battery Cable (-), 7", Eye/Eye, 4 AWG
23 1019674 1 Battery Cable (-), 18", Eye/Eye, 1/0 AWG
24 1019675 1 Battery Cable (-), 12.5", Eye/Eye, 1/0 AWG
25 1019676 1 Battery Cable (+), 12.5", Eye/Eye, 1/0 AWG
26 1019677 1 Battery Cable (-), 30", Eye/Eye, 1/0 AWG
27 1019678 1 Battery Cable (+), 32", Eye/Eye, 1/0 AWG
28 1019679 1 Battery Cable (+), 13", Eye/Eye, 1/0 AWG
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-85
