Item
No
Part Number Qty Description Remarks
OPT 982106 1 OPTION - Rear Window Wiper/Washer
1 151170 1 Windshield Wiper Motor
2 151180 1 Windshield Wiper Arm
3 151190 1 Windshield Wiper Blade, 20"
4 73119-CMG 1 Wiper/Washer Switch
5 852810 1 Windshield Washer Nozzle Kit
6 1011124 1 Wiper Motor Cover Plate
7 100-6-16-16-5F 2 CSHH, 3/8-16 x 1.00, GR5, FT
8 301-6 2 Washer, Flat, USS, 3/8
9 81277 1 CSBHS, 1/4-20 x .88, SS
10 35550 5 Windshield Washer Hose, .188 ID (per foot) Not Shown
11 300-6 2 Washer, Flat, SAE, 3/8 Not Shown
OPTION - Rear Wiper
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-97
