LeeBoy 685D - Page 31

Table 2-3. Electrical Specications
ITEM SPECIFICATION
Batteries (2) 12 VDC, Maintenance Free
Cold Cranking Amps (CCA) 800 CCA Per Battery (1600 CCA Total)
Alternator 135 amp
Table 2-5. Operational Specications
ITEM SPECIFICATION
Travel Speed (@ 2200 RPMs) 0 - 20 mph (0- 32.2 kph)
Recommended Speed While Grading 0 - 10 mph (0 - 16 kph)
Table 2-6. Fuel and Lubricant Specications
ITEM SPECIFICATION
Engine Oil API CJ-4 or ACEA-E9 (Low Ash) 15W40 WT
Hydraulic Oil AW32 or AW68 Hydraulic Oil
Coolant Ethylene/Glycol or Propylene Glycol
Fuel Ultra Low Sulphur Diesel (ULSD)
Transfer Case (2-Speed) 80-90 WT Gear Oil
Tandem Gear Box 80-90 WT Gear Oil
Differential Oil 80-90 WT Gear Oil
Planetary Hub 80-90 WT Gear Oil
Grease Shell Avania EP Grease or Equivalent
Table 2-7. Machine System Capacity Specications
ITEM SPECIFICATION
Fuel 45 gal (170.3 L)
Engine Lubrication Oil 15.4 qt (14.6 L)
Engine Coolant 5.75 gal (22 L)
Hydraulic Oil Reservoir 30 gal (113.56 L)
Transfer Case (2-Speed) .92 gal (3.48 L)
Differential Oil 2.2 gal (8.4 L)
Planetary Hub .63 gal (2.4 L) per hub
Tandem Gear Box 2.32 gal (8.78 L) per side
Table 2-8. Chassis Specications
ITEM SPECIFICATION
Tires 15-19.5 TL 8PR; 30 PSI
Brakes
Foot-Operated, hydrostatic traction drive system.
Hydraulic park brake is electrically actuated.
Front Drive Axle
Oscillating axle supported by tapered roller bearings
and bushings. Wheel lean 15° left or right. Ground
clearance of 1.2 feet (.36 m)
2
LeeBoy 685D Motor Grader
2-5
Information and Specications
