HYDRAULIC HOSE INDEX
Hose
No.
Qty. Part Number Description
1018254 Hydraulic Hose Kit - 2WD
1 2 F387TCJCJ1060606-21 BOGIE AXLE REAR JUMPER
2 2 F387TCJCJ1060606-17 BOGIE AXLE FRONT JUMPER
3 1 F387TCJCJC060606-36 FWD/REV VALVE 2 TO BOGIE AXLE REAR
4 1 F387TCJCJ9060606-24 2 SPEED VALVE A TO BOGIE SHIFTER FRONT
5 1 F387TCJCJ5060606-25 2 SPEED VALVE B TO BOGIE SHIFTER REAR
6 1 F387TCJCJ9040404-14 LP SWITCH TO CHARGE VALVE TEE
7 1 F387TCJCJ7080808-29 RELIEF VALVE T TOP CHARGE VALVE
8 1 F387TCJCJ9080808-28 RELIEF VALVE OUT TO CHARGE VALVE P
9 1 F387TCJCJC080808-45 GEAR PUMP TO BRAKE SYSTEM RELIEF VALVE
10 1 F387TCJCJ7080808-54 10 STATION VALVE PBR TO RETURN MANIFOLD
11 1 F387TCJCJ7080808-54 10 SECTION VALVE T TO RETURN MANIFOLD
12 1 F387TCJCJC080808-71 GEAR PUMP TO 10 SECTION VALVE P
13 1 F387TCJCJ7080808-54 10 SECTION VALVE D TO RETURN MANIFOLD
14 1 F387TCJCJ9080808-81 BRAKE CHARGE VALVE TO STEERIING MOTOR
15 1 F387TCJ5J7080808-66-0 STEERING MOTOR TO RETURN MANIFOLD
20 1 F797TCJCJC161616-23 RWD PUMP A TO DRIVE MOTOR A
21 1 F797TCJCJC161616-58 RWD PUMP B TO DRIVE MOTOR B
22 1 F387TCJCJC060606-15 RWD PUMP DESTROKE TOP TO VALVE
23 1 F387TCJCJC060606-18 RWD PUMP DESTROKE BOTTOM TO VALVE
24 1 F387TCJ9J9060606-27-90 TRANS SHIFT VALVE P TO BRAKE VALVE 3
25 1 F387TCJ9J9060606-23-0 TRANS SHIFT VALVE T TO BRAKE VALVE 1
26 1 F387TCJCJC060606-41 RWD PUMP FILTER AUX TO BRAKE VALVE 1
27 1 F387TCJCJ9060606-62 BRAKE VALVE 3 TO TANK
28 1 K811HTJSJS202020-60 TANK TO RWD PUMP SUCTION
29 1 K811HTJSJS242424-36 TANK TO GEAR PUMP SUCTION
30 1 F387TCJCJC121212-61 DRIVE MOTOR CASE DRAIN TO TANK
31 1 F387TCJCJ5121212-65 RWD PUMP CASE DRAIN TO TANK
32 1 F387TCJCJ9080808-23 BRAKE RELIEF VALVE TO RETURN MANIFOLD
33 1 F387TCJCJC121212-91 RADIATOR BOTTOM TO RETURN MANIFOLD
34 1 F387TCJCJC121212-45 RADIATOR TOP TO RETURN FILTER
35 1 F387TCJCJ7101010-35 RWD PUMP FILTER AUX TO CHARGE FILTER OUT
36 1 F387TCJCJ7101010-38 RWD PUMP FILTER AUX TO CHARGE FILTER IN
37 1 F387TCJCJ9101010-22 ENGINE OIL PAN TO REMOTE FITTING ON AXLE
38 1 F387TCJCJC060606-206 WHEEL LEAN VALVE A TO CYLINDER ROD END
39 1 F387TCJCJC060606-198 WHEEL LEAN VALVE B TO CYLINDER CAP END
40 1 F387TCJCJC060606-170 DOZER LIFT VALVE A TO LH BULKHEAD
41 1 F387TCJCJC060606-173 DOZER LIFT VALVE B TO RH BULKHEAD
42 1 F387TCJCJC060606-210 STEERING MOTOR TO CYLINDER ROD END
43 1 F387TCJCJ5060606-201 STEERING MOTOR TO CYLINDER CAP END
Hydraulic Hose Index
LeeBoy 685D Motor Grader7-104
