LeeBoy 685D - Page 316

Hose
No.
Qty. Part Number Description
1018646 Hydraulic Hose kit - Dozer/Front Scarier
1 1 F387TCJCJ9060606-18 DOZER FLOAT VALVE 2 TO LH BULKHEAD
2 1 F387TCJCJ9060606-18 DOZER FLOAT VALVE 1 TO RH BULKHEAD
3 1 F387TCJCJ9060606-34 DOZER LH BULKHEAD TO CYLINDER ROD END
4 1 F387TCJCJ9060606-34 DOZER RH BULKHEAD TO CYLINDER CAP END
Hose
No.
Qty. Part Number Description
1018640 Hydraulic Hose kit - Rear Scarier
4 2 F387TCJCJ9060606-18 SCARIFIER REAR BULKHEAD TO CYLINDER CAP END
5 2 F387TCJCJ9060606-34 SCARIFIER FRONT BULKHEAD TO CYLINDER ROD END
Hose
No.
Qty. Part Number Description
1018649 Hydraulic Hose kit - Circle Side Shift
1 1 F387TCJCJC060606-72 CIRCLE SHIFT VALVE A TO CYLINDER CAP END
2 1 F387TCJCJC060606-80 CIRCLE SHIFT VALVE B TO CYLINDER ROD END
Hose
No.
Qty. Part Number Description
1019628 Hydraulic Hose kit - Dead Engine Steering
1 1 F387TCJCJC060606-39 GEAR PUMP OUT TO DES PUMP CHECK VALVE
2 1 F387TCJCJ9060606-36 GEAR PUMP SUCTION TO DES PUMP SUCTION
Hydraulic Hose Index
LeeBoy 685D Motor Grader7-108
