LeeBoy 685D - Page 324

Description Part No.
Item
No.
Figure
No.
Charge Filter Assembly 1017484 REF 7-27
Charge Valve Weldment 1017529 1 7-29
Check Valve, 5 PSI, 8 GMP, -8 ORFS 1019694 8 7-46
Circle Side Shire Cylinder Assembly w/Adapters 1018414 REF 7-10
Circle Turn Cushion Valve 122084 6 7-28
Clamp Half 852827 4 7-6
Clamp, 4.00 1012526-38 22 7-35
Clevis Pin, 1.00 x 2.625 x 1.50 HD 210060 19 7-10
Clevis Pin, 1.00 x 2.63 w.1.50 Head 210060 3 7-1
Code 62 Adapter, 90°, -12 ORFS/-16 Flange FS1804-12-16-FG 39 7-32
Code 62 Adapter, 90°, -16 ORFS/-16 Flange FS1804-16-16-FG 22 7-31
Code 62 Adapter, 90°, -16 ORFS/-16 Flange FS1804-16-16-FG 24 7-32
Code 62 Clamp Flange, -16 1902-16 23 7-31
Code 62 Clamp Flange, -16 1902-16 25 7-32
Cold Control 12755496 8 7-19
Column Tilt Pedal 1019718 34 7-26
Compression Spring 38245 12 7-26
Condenser Assembly Binary Switch 12755077 4 7-18
Connector Adapter -16 ORFS/-16 NPTF FS2404-16-16 17 7-27
Connector, 6 Pin, 1018392 13 7-4
Connector, 6 Pin, DT04-6P-L012 1018392 14 7-7
Connector, 6-Pin, DT04-6P-L012 1018392 9 7-28
Console 1018088 1 7-22
Console Face Panel 1018090 2 7-22
Console Front 1018989 30 7-26
Contact Block, 1-NC 1010692 5 7-25
Control Lever 140531 14 7-23
Control Panel Assembly 1018235 REF 7-25
Coolant Control Valve 1013667-03 2 7-37
Coolant Level Sensor 988986 3 7-34
Coolant Pipe - Lower 1017545 18 7-34
Coolant Pipe - Upper 1017544 16 7-34
Cooling Unit 1017509-01 1 7-34
Cotter Pin, .188 x 2.00 80338 4 7-1
Cotter Pin, .188 x 2.00 80338 17 7-2
Cotter Pin, .188 x 2.00 80338 22 7-5
Cotter Pin, 1/4 x 2.25 130232 17 7-12
Cotter Pin, 1/8 x 1.00 80389 20 7-10
Cotter Pin, 3/16 x 2.00 80338 22 7-8
Alphabetical Parts Index
LeeBoy 685D Motor Grader7-116
