LeeBoy 685D - Page 342

Description Part No.
Item
No.
Figure
No.
Return Manifold 1019697 13 7-30
Rod End Ball Joint, 3/8" 100500 10 7-26
Rod End Ball Joint, 3/8" 100500 16 7-32
Roll Pin, 3/8 x 1.75 400-6-28 5 7-5
Roll Pin, 3/8 x 1.75 400-6-28 5 7-8
Rotary Latch - Left 983423-01SRV 8b 7-16
Rotary Latch - Right 983219-01SRV 8a 7-16
Round Ball Knob 851156 13 7-16
Rubber Elbow, 90°, 4.00 x 3.00 ID 1000834 4 7-35
Rubber Elbow, 90°, 5.00 x 4.00 ID 72172 10 7-35
Rubber Isolation Engine Mount (2 pc.) 1017509-26 26 7-36
Rubber Mount 36048 21 7-36
Run Tee Adapter, -12 ORFS/-12 O-Ring/-12 ORFS FS6804-12-12-12-NWO-FG 12 7-3
Run Tee Adapter, -6 ORFS/-6 O-Ring/-6 ORFS FS6804-06-06-06-NWO-FG 11 7-30
Run Tee Adapter, -8 ORFS/-8 O-Ring/-8 ORFS FS6804-08-08-08-NWO-FG 14 7-29
-S-
Scarier Cylinder Assembly w/Adapters 1018352 REF 7-43
Scarier Pin 1010773SRV 12 7-43
Scarier Point 100523 35 7-41
Scarier Shank Lock Pin 1020476 4 7-42
Scarier Shank w/Tooth 132040 2 7-42
Scarier Shank w/Tooth 132040 2 7-43
Scarier Tooth 132050 3 7-42
Scarier Tooth 132050 3 7-43
SCR 1017509-24 21 7-35
Screw, HWH, Slotted, #10-32 x 5/8 128-#10-32-10 9 7-27
Seal 210240 13 7-6
Seal 36830 20 7-6
Seat Assembly w/Seat Belt 1009335 1 7-20
Seat Box Access Panel 1010872 20 7-14
Seat Box Access Panel Plate 1010872 17 7-16
Seat Mount Plate 1020478 2 7-20
Seat Track Set 1009335-01 - 7-20
Set Screw Collar, 3/8" 1012918 13 7-26
Shoulder Bolt, 1/2-13, 1.25 LG 1019265 - 7-40
Side Cover 12757970 22 7-7
Side Glass 1013591-04 20 7-16
Signal Flasher 851091608 23 7-25
Alphabetical Parts Index
LeeBoy 685D Motor Grader7-134
