LeeBoy 685D - Page 346

Description Part No.
Item
No.
Figure
No.
Test Port Mount 1019090 19 7-30
Thick Washer w/Offset Hole 105571 31 7-31
Thick Washer w/Offset Hole 105571 33 7-32
Threaded Rod, 3/8-24 UNF x 11.00 56B-0692ZI 35 7-32
Threshold Plate 1010893 29 7-14
Threshold Plate 1010893 18 7-16
Throttle Control Lever 1018764 9 7-20
Throttle Control Mount 1018771 7 7-20
Throttle Plate, AWD Pump 1019449 34 7-32
Tie Rod Bushing, 1.25 ID x 1.50 OD x 1.00 LG 110130 3 7-6
Tie Rod, Wheel Lean 110182 23 7-5
Tie Rod, Wheel Lean 859375 23 7-8
Tire & Wheel Assembly - Right Rear 1010197R 2 7-3
Tire & Wheel Assembly -Left Rear 1010197L 3 7-3
Tire, 15" x 19.5", 8 Ply 110340 REF 7-4
Tire, 15" x 19.5", 8 Ply 100514 REF 7-7
Tire, 15: x 19.5", 8 PLY 100514 REF 7-3
Tire/Wheel Assembly - Left A120330AL 7 7-4
Tire/Wheel Assembly - Right A120330AR 6 7-4
Toggle Switch, DPDT, 3-POS 1018390 9 7-25
Toggle Switch, DPST, 2-POS 72086 12 7-25
Toggle Switch, SPDT, 2-POS 851090624 3 7-25
Toggle Switch, SPDT, 3-POS 851090613 10 7-25
Toggle Switch, SPST, 2-POS 851391 11 7-25
Torque Hub & Casting 1019685-01 11 7-9
Trans Shift Valve 983361 2 7-30
Trunnion Mount Assembly 100152SRV 8 7-2
Turn Signal w/Hazard 33687 22 7-22
Turntable & Drawbar Assembly 130004 1 7-10
Turntable & Drawbar Assembly 130004 REF 7-11
Turntable Bottom Plate 130083 26 7-11
Turntable Dust Cover 857578 1 7-11
-U, V-
Union Tee Adapter, -6 ORFS (x3) FS2603-06-06-06 23 7-3
Universal Back Plate 12758118 7 7-41
Universal Backplate 12758118 16 7-42
Valve Assembly, 10 Section w. Float 989177 REF 7-24
Valve Bank Assembly w/Adapters 1018344 REF 7-30
Alphabetical Parts Index
LeeBoy 685D Motor Grader7-138
