ITEM
NO.
CONTROL NAME FUNCTION
5
Right Turn Signal Indicator
Light
Blinks when the right turn signal is engaged.
6 High Gear Indicator Light Illuminates when operating in high gear.
7 High Beam Indicator Light Illuminates when the headlights are switched to high beam.
8 Moldboard Blade Angle Lever Rotates moldboard. Pull lever to rotate left; push lever to rotate right.
9 Moldboard Slide Lever
Shifts moldboard left or right. Pull lever to shift moldboard left; push lever
to shift moldboard right.
10 Moldboard Lift Lever (Left)
Raises/lowers left moldboard edge. Pull lever to raise left edge; push
lever to lower left edge. Continue to push lever forward into oat detent.
Push or pull both the left and right moldboard lift levers to raise and lower
the entire moldboard.
11 Moldboard Lift Lever (Right)
Raises/lowers right moldboard edge. Pull lever to raise right edge; push
lever to lower right edge. Continue to push lever forward into oat detent.
Push or pull both the left and right moldboard lift levers to raise and lower
the entire moldboard.
12 Circle Side Shift (Option)
Rotates drawbar left or right. Pull lever to shift drawbar left; push lever
to shift drawbar right. (This lever is nonfunctional if not equipped with
option.)
13
Front Attachment Lever
(Option)
Raises/lowers optional front attachments. Pull lever to raise, push lever
to lower. (This lever is nonfunctional if not equipped with option.)
14 Wheel Lean Lever
Tilts the front wheels left or right. Push lever forward to tilt tires left; pull
lever to tilt tires right.
15 Moldboard Tilt Lever
Tilts moldboard. Pull lever to tilt top of the moldboard backward. Push
lever to tilt top of moldboard forward.
16 Rear Scarier Lever (Option) Raises/lowers rear attachment. Pull lever to raise; push lever to lower.
17 Articulate Lever
Rotates front “boom” portion of the grader. Pull lever to rotate boom right;
push lever to rotate boom left.
NOTE: The articulation angle can affect the stability of the
machine. Efcient and safe articulation requires skill and
experience to take advantage of its full capabilities.
3
Components
3-9LeeBoy 685D Motor Grader
