Screen Brightness
Use the UP/DOWN soft keys and stop the cursor (>)
next to the action item Brightness. (Figure 4-15) Set
the brightness of the backlight by using the +/– soft keys.
Figure 4-15. Set Brightness Of Backlight Screen
Language
Use the UP/DOWN soft keys and stop the cursor (>)
next to the action item Language. (Figure 4-16) Set
your language preference using the +/– soft keys.
(English, French, German, Spanish, Italian or Japanese)
Figure 4-16. Set Language Preferences Screen
Units
Use the UP/DOWN soft keys and stop the cursor (>)
next to the action item Units. (Figure 4-17) Set your unit
preference using the +/– soft keys. (US Standard, Metric
kPa or Metric Bar.)
Figure 4-17. Set Unit Preferences Screen
