LELY Vector - Page 120

5.2011.8583.0 C
6-14 Maintenance Procedures
Removal
1. Remove the two nuts, washers and bolts and the old mixer knife (2) or (3) (see figure 62 on page 6-14).
Figure 62. Install or remove the mixer knives
KEY: 1. Bolts M12x35 - 2. Small knife - 3. Bolts M16x45 - 4. Big knife - 5. Locking pin
