Page 362
MegaRAID SAS Software User GuideChapter 11: Using MegaRAID® Advanced Software
| SafeStore Encryption Services
Import Foreign Drives — LKM mode, EKM Secured Locked Drives are present.
Import Foreign Drives — EKM mode, LKM secured locked drives are present.
Import Foreign Drives — EKM mode, EKM secured locked drives are present.
Perform the following steps to configure the Scan Foreign Configuration wizard.
1. Select the Physical View tab in the left panel of the MegaRAID Storage Manager
window, and click a controller icon.
2. Choose any one of the following options to enable the Scan Foreign
Configuration wizard.
Right-click the controller node in the device tree in the left frame of the MegaRAID
Storage Manager window, and select Scan Foreign Configuration.
Select Go To>Controller>Scan Foreign Configuration in the main navigation bar
present in the top portion of the MSM screen.
If a Foreign Configuration is detected, the “Foreign Configuration Detected” screen
appears. If you choose “Import” and click OK, the Unlock Foreign drives wizard
appears as shown in Figure250.
11.5.6 Importing Foreign Drives to
LKM
When the VD is secured with the EKM mode, and if you change the security settings
from the EKM mode to LKM mode, and want to import those foreign configured VDs,
then the following dialog box appears.
Figure 249: Importing Foreign Drives- EKM to LKM
11.5.7 Importing Foreign Drives to
EKM
When the VD is secured with the LKM mode, and want to switch from LKM to EKM, and
if the VD is in Foreign state, and if you want to import those foreign configuration, you
must provide the LKM key for each VD.
