Front bays Ma-
x.
Am-
bi-
ent
Te-
mp.
(at
sea
lev-
el)
Processor Heat
sink
Fan
type
Ma-
x.
PCI-
e/
OCP
Qty
Cable
• 10 x 2.5" AnyBay
• 10 x 2.5" NVMe
• 10 x 2.5" SAS/SATA
• 8 x2.5'' SAS/SATA
• 6 x 2.5" SAS/SATA + 4 x
2.5" AnyBay
• 6 x 2.5" SAS/SATA + 2 x
2.5" AnyBay + 2 x 2.5"
NVMe
• 16-EDSFF
30°C
A and B Perf Perf 3
AOC/DAC
25°C E (except 9654/9654P processors) CL
n-
ote
Perf 3 Without
100G AOC
25°C E (9654/9654P processors only) Perf Perf 3 Without
100G AOC
30°C
E
CL
n-
ote
Perf 3 Without
100G AOC
• 4x2.5'' SAS/SATA
• 4x2.5'' NVMe
• 4x2.5' AnyBay
30°C
B Perf Perf 3
AOC/DAC
30°C
A Perf Perf 3
AOC/DAC
25°C E (except 9654/9654P/9174F/9554/
9554P processors)
CL Perf 3 AOC/DAC
25°C E (9174F/9554/9554P processors only) Perf Perf 3 AOC/DAC
30°C E (9654/9654P processors only) Perf Perf 3 AOC/DAC
30°C E (except 9654/9654P processors ) CL Perf 3 Without
100G AOC
Fan locations and supported quantity for different configurations
The supported fan quantity and suggested installation slots vary with different configurations. See the
following table for details.
Configurations
Limiting conditions Fan
quan-
tity
Fan type Fan
loca-
tions
(slots)
Fan
dum-
my
quan-
tity
• 16-EDSFF
• 4x2.5'' SAS/SATA
• 4x2.5'' NVMe
• 4x2.5' AnyBay
• No OCP module installed on the rear and
no 2nd BMC manager port adapter
installed
• No adapter installed in PCIe slot 1
• No GPU adapter
6 Perf 2, 3, 4,
5, 6, 7
2
Other scenarios except the above
7
Perf 1, 2, 3,
4, 5, 6,
7
1
58 ThinkSystem SR635 V3 User Guide
