Display code Short designaon Default seng Seng range Address Category
P790.00 Quick stop dec. 546000 pos. unit/s² 0 ... 2147483647 pos. unit/s² 0x6085 general
P791.00 Fault reacon Coasng [0] Selecon list 0x605E general
P800.00 Sequencer mode Disabled [0] Selecon list 0x4025 general
P801.xx Segment 1
└ P801.01 Frequency setp. 0.0 Hz -599.0 ... 599.0 Hz 0x4026:001 general
└ P801.02 Accel./decel. 5.0 s 0.0 ... 3600.0 s 0x4026:002 general
└ P801.03 Time 0.0 s 0.0 ... 100000.0 s 0x4026:003 general
└ P801.04 Digital outp. 0 0 ... 255 0x4026:004 general
└ P801.05 Analog outp. 0.00 VDC 0.00 ... 10.00 VDC 0x4026:005 general
└ P801.06 PID setp. 0.00 PID unit -300.00 ... 300.00 PID unit 0x4026:006 general
└ P801.07 Torque setp. 100.0 % -400.0 ... 400.0 % 0x4026:007 general
P802.xx Segment 2
└ P802.01 Frequency setp. 0.0 Hz -599.0 ... 599.0 Hz 0x4027:001 general
└ P802.02 Accel./decel. 5.0 s 0.0 ... 3600.0 s 0x4027:002 general
└ P802.03 Time 0.0 s 0.0 ... 100000.0 s 0x4027:003 general
└ P802.04 Digital outp. 0 0 ... 255 0x4027:004 general
└ P802.05 Analog outp. 0.00 VDC 0.00 ... 10.00 VDC 0x4027:005 general
└ P802.06 PID setp. 0.00 PID unit -300.00 ... 300.00 PID unit 0x4027:006 general
└ P802.07 Torque setp. 100.0 % -400.0 ... 400.0 % 0x4027:007 general
P803.xx Segment 3
└ P803.01 Frequency setp. 0.0 Hz -599.0 ... 599.0 Hz 0x4028:001 general
└ P803.02 Accel./decel. 5.0 s 0.0 ... 3600.0 s 0x4028:002 general
└ P803.03 Time 0.0 s 0.0 ... 100000.0 s 0x4028:003 general
└ P803.04 Digital outp. 0 0 ... 255 0x4028:004 general
└ P803.05 Analog outp. 0.00 VDC 0.00 ... 10.00 VDC 0x4028:005 general
└ P803.06 PID setp. 0.00 PID unit -300.00 ... 300.00 PID unit 0x4028:006 general
└ P803.07 Torque setp. 100.0 % -400.0 ... 400.0 % 0x4028:007 general
P804.xx Segment 4
└ P804.01 Frequency setp. 0.0 Hz -599.0 ... 599.0 Hz 0x4029:001 general
└ P804.02 Accel./decel. 5.0 s 0.0 ... 3600.0 s 0x4029:002 general
└ P804.03 Time 0.0 s 0.0 ... 100000.0 s 0x4029:003 general
└ P804.04 Digital outp. 0 0 ... 255 0x4029:004 general
└ P804.05 Analog outp. 0.00 VDC 0.00 ... 10.00 VDC 0x4029:005 general
└ P804.06 PID setp. 0.00 PID unit -300.00 ... 300.00 PID unit 0x4029:006 general
└ P804.07 Torque setp. 100.0 % -400.0 ... 400.0 % 0x4029:007 general
P805.xx Segment 5
└ P805.01 Frequency setp. 0.0 Hz -599.0 ... 599.0 Hz 0x402A:001 general
└ P805.02 Accel./decel. 5.0 s 0.0 ... 3600.0 s 0x402A:002 general
└ P805.03 Time 0.0 s 0.0 ... 100000.0 s 0x402A:003 general
└ P805.04 Digital outp. 0 0 ... 255 0x402A:004 general
└ P805.05 Analog outp. 0.00 VDC 0.00 ... 10.00 VDC 0x402A:005 general
└ P805.06 PID setp. 0.00 PID unit -300.00 ... 300.00 PID unit 0x402A:006 general
└ P805.07 Torque setp. 100.0 % -400.0 ... 400.0 % 0x402A:007 general
P806.xx Segment 6
└ P806.01 Frequency setp. 0.0 Hz -599.0 ... 599.0 Hz 0x402B:001 general
└ P806.02 Accel./decel. 5.0 s 0.0 ... 3600.0 s 0x402B:002 general
└ P806.03 Time 0.0 s 0.0 ... 100000.0 s 0x402B:003 general
└ P806.04 Digital outp. 0 0 ... 255 0x402B:004 general
└ P806.05 Analog outp. 0.00 VDC 0.00 ... 10.00 VDC 0x402B:005 general
└ P806.06 PID setp. 0.00 PID unit -300.00 ... 300.00 PID unit 0x402B:006 general
└ P806.07 Torque setp. 100.0 % -400.0 ... 400.0 % 0x402B:007 general
P807.xx Segment 7
└ P807.01 Frequency setp. 0.0 Hz -599.0 ... 599.0 Hz 0x402C:001 general
└ P807.02 Accel./decel. 5.0 s 0.0 ... 3600.0 s 0x402C:002 general
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
