Lenze i55AE155F

Parameter Name / value range / [default seng] Info
0x2349
(P517.00)
PROFIBUS error
(PROFIBUS error)
•
Read only
Bit-coded display of PROFIBUS errors.
Bit 0 Watchdog elapsed Communicaon with the PROFIBUS master is connuously interrupted,
e. g. by cable break or failure of the PROFIBUS master.
•
No process data are sent to the inverter (slave) in the "Data Exchange"
state.
•
When the watchdog monitoring me specied by the master has
elapsed, the response set in 0x2859:001 (P515.01) is triggered in the
inverter.
Precondions for a response by the inverter (slave):
•
The slave is in the "Data Exchange" state.
•
The watchdog monitoring me is congured correctly in the master
(1 ... 65535 ms).
If one of these precondions is not met, the response to the absence of
cyclic process data telegrams from the master is not executed.
Bit 1 Data exchange completed Data exchange via PROFIBUS has been terminated.
•
The inverter (slave) can be instructed by the master to exit the "Data
Exchange" state.
•
If this state change is to be treated as an error in the inverter, the
desired response can be set in 0x2859:002 (P515.02).
Bit 2 Incorrect conguraon data The inverter (slave) has received invalid conguraon data from the
master.
•
The response set in 0x2859:003 (P515.03) is eected.
Bit 3 Inialisaon error An error has occurred during the inialisaon of the PROFIBUS interface.
•
The response set in 0x2859:004 (P515.04) is eected.
Bit 4 Invalid process data The inverter (slave) has received invalid process data from the master,
e.g. no process data or deleted process data are sent by the "Stop" oper-
ang status in the master.
•
The response set in 0x2859:005 (P515.05) is eected.
0x234A:001
(P580.01)
PROFIBUS stascs: Data cycles per second
(PROFIBUS counter: Data cycles/sec.)
•
Read only
Display of the data cycles per second.
0x234A:002
(P580.02)
PROFIBUS stascs: Parameterizaon events
(PROFIBUS counter: PRM events)
•
Read only
Display of the number of parameterisaon events.
0x234A:003
(P580.03)
PROFIBUS stascs: Conguraon events
(PROFIBUS counter: CFG events)
•
Read only
Display of the number of conguraon events.
0x234A:004
(P580.04)
PROFIBUS stascs: Diagnoscs events
(PROFIBUS counter: DIAG events)
•
Read only
Display of the number of diagnosc telegrams sent.
0x234A:005
(P580.05)
PROFIBUS stascs: C1 messages
(PROFIBUS counter: C1 messages)
•
Read only
Display of the number of requests by the class 1 DPV1 master.
0x234A:006
(P580.06)
PROFIBUS stascs: C2 messages
(PROFIBUS counter: C2 messages)
•
Read only
Display of the number of requests by the class 2 DPV1 master.
0x234A:007
(P580.07)
PROFIBUS stascs: Watchdog events
(PROFIBUS counter: WD events)
•
Read only
Display of the number of watchdog events.
0x234A:008
(P580.08)
PROFIBUS stascs: Data exchange aborts
(PROFIBUS counter: DataEx.event)
•
Read only
Display of the number of "Data Exchange exited" events.
0x234A:009
(P580.09)
PROFIBUS stascs: Total data cycles
(PROFIBUS counter: Tot. data cycles)
•
Read only
Display of the number of cyclic process data received.
Related topics
4PROFIBUS ^ 294
Diagnoscs and fault eliminaon
Diagnoscs parameter
Network diagnoscs
