Lenze i55AE155F

Parameter format
Byte 5 Byte 6
Format Number of values
Field Data type Values
Format U8 0x02: integer8 (1 byte with sign)
0x03: Integer16 (2 bytes with sign)
0x04: Integer32 (4 bytes with sign)
0x05: Unsigned8 (1 byte without sign)
0x06: Unsigned16 (2 bytes without sign)
0x07: Unsigned32 (4 bytes without sign)
0x09: Visible String (with n characters)
0x0A: Octet String (with n characters)
0x40: Zero
0x41: Byte
0x42: Word
0x43: Double word
Number of values U8 0x01 or number of characters (n) for string parameters.
Parameter value
Byte 7 Byte 8 Byte 9 Byte 10
Value
(Integer8 / Unsigned8 / byte)
Value
(Integer16 / Unsigned16 / word)
Value
(Integer32 / Unsigned32 / double word)
Byte 7 Byte 8 Byte 9 Byte ...
String
(Visible String / octet string with an oponal length)
Field Data type Values
Value U8/U16/U32 Value range/length depends on the parameter format (see table above).
String U8 Visible string / octet string with an oponal length (n characters = n
bytes)
Response to a read error
In the case of a mul-parameter request, correct and possible faulty messages are summar-
ised in one telegram. They have the following data contents:
Correct message
•
Format: data type of the value requested
•
Number of values: as described above.
•
Parameter value: value requested
Faulty message
•
Format: 0x44
•
Number of values: 0x01 or 0x02
•
Error code without addional informaon (for number of values = 0x01) or error code with
addional informaon (for number of values = 0x02)
A faulty access to a parameter "n" is indicated at the nth posion in the response telegram of
a mul-parameter request.
Conguring the network
PROFIBUS
Read parameter data
306
