Lenze i55AE155F

Data transfer with funcon code 6
Request
Funcon code 0x06
Register address 0x0000 ... 0xFFFF
Register value 0x0000 ... 0xFFFF
Response
Funcon code 0x06
Register address 0x0000 ... 0xFFFF
Register value 0x0000 ... 0xFFFF
Error message
Funcon code in the event of an
error
0x86
Error code 01 ... 04
Example for data transfer with funcon code 6
The value "3" (0x0003) is to be wrien into the register 40002.
Request Info
Funcon code 0x06 Funcon code 6
Register address (High) 0x00 Register address for register 40002: 1 (0x0001)
Register address (Low) 0x01
Register value (High) 0x00 Value to be wrien into the register: 3 (0x0003)
Register value (Low) 0x03
Response Info
Funcon code 0x06 Funcon code 6
Register address (High) 0x00 Register address: 1 (0x0001)
Register address (Low) 0x01
Register value (High) 0x00 Register value: 3 (0x0003)
Register value (Low) 0x03
Data transfer with funcon code 16
Request
Funcon code 0x10
Start address 0x0000 ... 0xFFFF
Number of registers (n) 0x0001 ... 0x7D (0d125)
Number of bytes 2 x (number of registers)
Register value Data in (n) register of 2 bytes each
Response
Funcon code 0x10
Number of bytes 2 x (number of registers)
Register values Data in (n) register of 2 bytes each
Error message
Funcon code in the event of an
error
0x90
Error code 01 ... 04
Conguring the network
Modbus TCP
Funcon codes
357
