Lenze i55AE155F

5 Commissioning 71
5.1 Important notes 71
5.2 Operang interfaces 72
5.2.1 Keypad 72
5.2.2 Engineering tool »EASY Starter« 73
5.2.2.1 Generate a connecon between inverter and »EASY Starter« 74
5.3 Parameter seng 76
5.3.1 General notes on parameters 77
5.3.2 Basic inverter sengs 78
5.3.3 Basic motor sengs 81
5.3.4 Funcon assignment of the inputs and outputs 82
5.4 Keypad parameter list 85
5.5 Save parameter sengs in the memory module 107
5.5.1 Save parameter sengs with keypad 107
5.5.2 Save parameter sengs with »EASY Starter« 107
6 Diagnoscs and fault eliminaon 108
6.1 LED status display 108
6.2 Diagnoscs parameter 109
6.2.1 Logbook 110
6.2.2 Error history buer 111
6.2.3 Inverter diagnoscs 114
6.2.4 Network diagnoscs 118
6.2.4.1 CANopen diagnoscs 119
6.2.4.2 Modbus diagnoscs 122
6.2.4.3 PROFIBUS diagnoscs 122
6.2.4.4 EtherNet/IP diagnoscs 125
6.2.4.5 PROFINET diagnoscs 126
6.2.4.6 EtherCAT diagnoscs 127
6.2.4.7 POWERLINK diagnoscs 128
6.2.5 Diagnoscs of the inputs and outputs 129
6.2.5.1 Digital inputs and outputs 129
6.2.5.2 Analog inputs and outputs 130
6.2.6 Wireless-LAN diagnoscs 132
6.2.7 Setpoint diagnosc 133
6.2.8 Process controller status 133
6.2.9 Sequencer diagnoscs 134
6.2.10 Device idencaon 135
6.2.11 Device overload monitoring (i*t) 136
6.2.12 Heatsink Temperature Monitoring 137
6.2.13 Life-diagnosis 137
6.3 Error handling 139
6.3.1 Error types 139
6.3.2 Error conguraon 140
6.3.3 Error reset 140
6.3.4 Keypad error messages 140
6.4 Data handling 141
Contents
4
