Lenze i55AE155F

Mains connecon
Inverter I55AE125D
I55AE137D
I55AE155D
I55AE175D
I55AE211D
I55AE215D
I55AE222D
I55AE240C
I55AE255C
Connecon X100
Connecon type pluggable screw terminal Screw terminal
Min. cable cross-secon mm² 1 1.5
Min. cable cross-secon AWG 18 16
Max. cable cross-secon mm² 2.5 6
Max. cable cross-secon AWG 12 10 8
Stripping length mm 8 9
Stripping length inch 0.32 0.35
Tightening torque Nm 0.5 0.7 0.5
Tightening torque lb-in 4.4 6.2 4.4
Required tool 0.5 x 3.0 0.6 x 3.5
PE connecon
Inverter I55AE125D
I55AE137D
I55AE155D
I55AE175D
I55AE211D
I55AE215D
I55AE222D
I55AE240C
I55AE255C
Connecon PE
Connecon type PE screw
Min. cable cross-secon mm² 1.5
Min. cable cross-secon AWG 14
Max. cable cross-secon mm² 6
Max. cable cross-secon AWG -
Stripping length mm 10
Stripping length inch 0.39
Tightening torque Nm 2
Tightening torque lb-in 18
Required tool TORX TX20
Motor connecon
Inverter I55AE125D
I55AE137D
I55AE155D
I55AE175D
I55AE211D
I55AE215D
I55AE222D
I55AE240C
I55AE255C
Connecon X105
Connecon type pluggable screw terminal Screw terminal
Min. cable cross-secon mm² 1 1.5
Min. cable cross-secon AWG 18 16
Max. cable cross-secon mm² 2.5 6
Max. cable cross-secon AWG 12 8
Stripping length mm 8 9
Stripping length inch 0.32 0.35
Tightening torque Nm 0.5
Tightening torque lb-in 4.4
Required tool 0.5 x 3.0 0.6 x 3.5
Electrical installaon
Mains connecon
3-phase mains connecon 230/240 V
40
