Lenze i55AE155F

Mains connecon
Inverter I55AE230F
I55AE240F
I55AE255F
I55AE275F
I55AE311F
I55AE315F
I55AE318F
I55AE322F
I55AE330F
I55AE337F
I55AE345F
I55AE355F
I55AE375F
I55AE390F
Connecon X100
Connecon type Screw terminal
Min. cable cross-secon mm² 1.5 10 25 35
Min. cable cross-secon AWG 16 6 2 1
Max. cable cross-secon mm² 6 16 35 50 95 150
Max. cable cross-secon AWG 10 6 2 1/0 4/0 -
Stripping length mm 9 11 18 19 22 28
Stripping length inch 0.35 0.43 0.7 0.75 0.87 1.1
Tightening torque Nm 0.5 1.2 3.8 4 10 18
Tightening torque lb-in 4.4 11 34 35 89 160
Required tool 0.6 x 3.5 0.8 x 4.0 0.8 x 5.5 Allen key 4.0 Allen key 6.0 Allen key 8.0
Motor connecon
Inverter I55AE230F
I55AE240F
I55AE255F
I55AE275F
I55AE311F
I55AE315F
I55AE318F
I55AE322F
I55AE330F
I55AE337F
I55AE345F
I55AE355F
I55AE375F
I55AE390F
Connecon X105
Connecon type Screw terminal
Min. cable cross-secon mm² 1.5 10 25 35
Min. cable cross-secon AWG 16 6 2 1
Max. cable cross-secon mm² 6 16 35 50 95 150
Max. cable cross-secon AWG -
Stripping length mm 9 11 18 19 22 28
Stripping length inch 0.35 0.43 0.7 0.75 0.87 1.1
Tightening torque Nm 0.5 1.2 3.8 4 10 18
Tightening torque lb-in 4.4 11 34 35 89 160
Required tool 0.6 x 3.5 0.8 x 4.0 0.8 x 5.5 Allen key 4.0 Allen key 6.0 Allen key 8.0
Electrical installaon
Mains connecon
3-phase mains connecon 400 V "light duty"
