Lenze i55AE155F

Parameter Name / value range / [default seng] Info
0x4034:001 ...
0x4034:016
(P840.01 ... 16)
Sequence 3: Step 1 ... Step 16
(Sequence 3: Step 1 ... Step 16)
Conguraon of the steps 1 ... 16 for sequence 3.
•
Alternavely to calling a single segment, a complete sequence (with a
higher number) can also be called from one step. This, for instance,
serves to congure a main sequence from which several subsequen-
ces are called successively.
•
With the seng "0", the respecve step is skipped.
-8 Sequence 8
-7 Sequence 7
-6 Sequence 6
-5 Sequence 5
-4 Sequence 4
0 Skip step
1 Segment 1
2 Segment 2
3 Segment 3
4 Segment 4
5 Segment 5
6 Segment 6
7 Segment 7
8 Segment 8
0x4035
(P841.00)
Number of cycles sequence 3
(Cycl. sequence 3)
1 ... [1] ... 65535
•
From version 03.00
Denion of how oen the sequence 3 is to be passed through.
•
1 = one pass, 2 = two passes, ...
•
65535 = innite number of cycles.
0x4036:001 ...
0x4036:016
(P845.01 ... 16)
Sequence 4: Step 1 ... Step 16
(Sequence 4: Step 1 ... Step 16)
Conguraon of the steps 1 ... 16 for sequence 4.
•
Alternavely to calling a single segment, a complete sequence (with a
higher number) can also be called from one step. This, for instance,
serves to congure a main sequence from which several subsequen-
ces are called successively.
•
With the seng "0", the respecve step is skipped.
-8 Sequence 8
-7 Sequence 7
-6 Sequence 6
-5 Sequence 5
0 Skip step
1 Segment 1
2 Segment 2
3 Segment 3
4 Segment 4
5 Segment 5
6 Segment 6
7 Segment 7
8 Segment 8
0x4037
(P846.00)
Number of cycles sequence 4
(Cycl. sequence 4)
1 ... [1] ... 65535
•
From version 03.00
Denion of how oen the sequence 4 is to be passed through.
•
1 = one pass, 2 = two passes, ...
•
65535 = innite number of cycles.
0x4038:001 ...
0x4038:016
(P850.01 ... 16)
Sequence 5: Step 1 ... Step 16
(Sequence 5: Step 1 ... Step 16)
Conguraon of the steps 1 ... 16 for sequence 5.
•
Alternavely to calling a single segment, a complete sequence (with a
higher number) can also be called from one step. This, for instance,
serves to congure a main sequence from which several subsequen-
ces are called successively.
•
With the seng "0", the respecve step is skipped.
-8 Sequence 8
-7 Sequence 7
-6 Sequence 6
0 Skip step
1 Segment 1
2 Segment 2
3 Segment 3
4 Segment 4
5 Segment 5
6 Segment 6
7 Segment 7
8 Segment 8
0x4039
(P851.00)
Number of cycles sequence 5
(Cycl. sequence 5)
1 ... [1] ... 65535
•
From version 03.00
Denion of how oen the sequence 5 is to be passed through.
•
1 = one pass, 2 = two passes, ...
•
65535 = innite number of cycles.
Sequencer
Sequence conguraon
518
