Lenze i55AE155F

Mains connecon
Inverter I55AE137F
I55AE155F
I55AE175F
I55AE211F
I55AE215F
I55AE222F
I55AE230F
I55AE240F
I55AE255F
I55AE275F
I55AE311F
I55AE315F
I55AE318F
I55AE322F
I55AE330F
I55AE337F
I55AE345F
I55AE355F
I55AE375F
Connecon X100
Connecon type pluggable
screw terminal
Screw terminal
Min. cable cross-secon mm² 1 1.5 10 25
Min. cable cross-secon AWG 18 16 6 2
Max. cable cross-secon mm² 2.5 6 16 35 50 95
Max. cable cross-secon AWG 12 10 6 2 1/0 4/0
Stripping length mm 8 9 11 18 19 22
Stripping length inch 0.32 0.35 0.43 0.7 0.75 0.87
Tightening torque Nm 0.5 1.2 3.8 4 10
Tightening torque lb-in 4.4 11 34 35 89
Required tool 0.5 x 3.0 0.6 x 3.5 0.8 x 4.0 0.8 x 5.5 Allen key 4.0 Allen key 6.0
PE connecon
Inverter I55AE137F
I55AE155F
I55AE175F
I55AE211F
I55AE215F
I55AE222F
I55AE230F
I55AE240F
I55AE255F
I55AE275F
I55AE311F
I55AE315F
I55AE318F
I55AE322F
I55AE330F
I55AE337F
I55AE345F
I55AE355F
I55AE375F
Connecon PE
Connecon type PE screw
Min. cable cross-secon mm² 1.5 2.5 4
Min. cable cross-secon AWG 14 12
Max. cable cross-secon mm² 6 16 25
Max. cable cross-secon AWG 10 6 2
Stripping length mm 10 11 16
Stripping length inch 0.39 0.43 0.63
Tightening torque Nm 2 3.4 4
Tightening torque lb-in 18 30 35
Required tool TORX TX20 PZ2
Electrical installaon
Mains connecon
3-phase mains connecon 480 V
56
