Lenze i55AE155F

t
t
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
-40 Hz
-60 Hz
-50 Hz
-30 Hz
-20 Hz
-10 Hz
t
t
t
t
t
t
0x2DDD
Running [50]
Stop active [53]
Run
Digital input 2 [12]
Constant TRUE [1]
Digital input 1 [11]
DC brake
DC brake
DC braking active [67]
Output signals
Status signals
Output frequency
Activate DC braking
Enable inverter
Input signals
Frequency setpoint selection
FunctionTrigger
The status signals can be assigned to digital outputs. 4Conguraon of digital outputs ^ 603
①
If DC braking is acvated while the motor is running, the output pulses of the inverter are disabled immediately. For stopping the motor, the
current set in 0x2B84:001 (P704.01) is injected. The exact drive behaviour depends on the sengs for the "DC braking" funcon and the
load properes.
Flexible I/O conguraon
Acvang DC braking manually
573
