Lenze i55AE155F

Parameter Name / value range / [default seng] Info
0x2634:016
(P420.16)
Digital outputs funcon: NetWordOUT1 - bit 6
(Dig.out.funcon: NetWordOUT1.06)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 603
Assignment of a trigger to bit 6 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
50 Running
0x2634:017
(P420.17)
Digital outputs funcon: NetWordOUT1 - bit 7
(Dig.out.funcon: NetWordOUT1.07)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 603
Assignment of a trigger to bit 7 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
58 Device warning acve
0x2634:018
(P420.18)
Digital outputs funcon: NetWordOUT1 - bit 8
(Dig.out.funcon: NetWordOUT1.08)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 603
Assignment of a trigger to bit 8 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
0 Not connected
0x2634:019
(P420.19)
Digital outputs funcon: NetWordOUT1 - bit 9
(Dig.out.funcon: NetWordOUT1.09)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 603
Assignment of a trigger to bit 9 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
0 Not connected
0x2634:020
(P420.20)
Digital outputs funcon: NetWordOUT1 - bit 10
(Dig.out.funcon: NetWordOUT1.10)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 603
Assignment of a trigger to bit 10 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
72 Setpoint speed reached
0x2634:021
(P420.21)
Digital outputs funcon: NetWordOUT1 - bit 11
(Dig.out.funcon: NetWordOUT1.11)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 603
Assignment of a trigger to bit 11 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
78 Current limit reached
0x2634:022
(P420.22)
Digital outputs funcon: NetWordOUT1 - bit 12
(Dig.out.funcon: NetWordOUT1.12)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 603
Assignment of a trigger to bit 12 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
71 Actual speed = 0
0x2634:023
(P420.23)
Digital outputs funcon: NetWordOUT1 - bit 13
(Dig.out.funcon: NetWordOUT1.13)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 603
Assignment of a trigger to bit 13 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
69 Rotaonal direcon reversed
0x2634:024
(P420.24)
Digital outputs funcon: NetWordOUT1 - bit 14
(Dig.out.funcon: NetWordOUT1.14)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 603
Assignment of a trigger to bit 14 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
115 Release holding brake
0x2634:025
(P420.25)
Digital outputs funcon: NetWordOUT1 - bit 15
(Dig.out.funcon: NetWordOUT1.15)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 603
Assignment of a trigger to bit 15 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
55 Safe torque o (STO) acve
0x2635:010 Inversion of digital outputs: NetWordOUT1.00 Inversion of bit 0 of NetWordOUT1.
0 Not inverted
1 Inverted
0x2635:011 Inversion of digital outputs: NetWordOUT1.01 Inversion of bit 1 of NetWordOUT1.
0 Not inverted
1 Inverted
0x2635:012 Inversion of digital outputs: NetWordOUT1.02 Inversion of bit 2 of NetWordOUT1.
0 Not inverted
1 Inverted
Flexible I/O conguraon
Conguraon of digital outputs
NetWordOUT1 status word
610
