Lexmark C910 Service Manual

2-32 Service Manual
5055-01X
996 - Finisher Jogging Motor Error
Step
Questions /
Actions
Yes No
1 Are there foreign
objects or
obstructions in the
jogging assembly?
Clear the objects or
obstruction.
Go to step 2.
2 Are the jogging
motor connectors
CN2 on the
finisher control
board securely
connected?
Go to step 3. Securely connect the
connectors.
3 Make sure the
finisher set switch
is activated.
Measure for +24 V
dc (+ or - 10%)
between pin 1 on
CN2 and frame
ground. Is +24 V
dc present?
Go to step 4. Go to step 5.
4 Replace the
jogging motor
assembly. Did this
resolve the
problem?
Problem solved. Replace the finisher
control board.
5 Disconnect CN2
and PJ5. Perform
a continuity check
on the cable for all
positions. Is there
continuity?
Go to step 6. Replace the cable.
