Diagnostic Information 2-85
5055-01X
Photodeveloper Missing Service Check
When you replace the photodeveloper unit, all three color units must
be replaced at the same time.
FRU Action
1 Photodeveloper Check for dirt or damage to the sensing contacts on
rear. Clean or replace the photodeveloper drum unit
if necessary.
2 Sub-frame Unit Check the sensing contacts on the sub-frame
assembly. Clean or replace the affected contacts or
sub-frame.
3 High Voltage
Unit
If the problem remains, replace the high voltage unit
(HVU).
4Printer
Controller
Board
If the problem remains, replace the printer controller
board.
To Next Page
