Lexmark C910 Service Manual

2-36 Service Manual
5055-01X
999 - Stapler Motor Error
3 Disconnect CN4 at
the tray elevator
motor. Disconnect
PJ4 on the finisher
control board.
Measure for
continuity between
CN4 pin 1 and PJ4
pin 7. Measure for
continuity between
CN4 pin 2 and PJ4
pin 8. Is there
continuity in both
locations?
Go to step 4. Replace the cable.
4 Measure for +24 V
dc (+ or -10%)
between pins 1 and
2 on connector PJ6.
Is +24 V dc present?
Replace the finisher
control board.
Replace the finisher
power supply.
Step
Questions /
Actions
Yes No
1 Are staples
jammed in the
stapler?
Go to step 2. Go to step 3.
2 Clear the staple
jam and run the
staple test in
diagnostic mode
or run a staple job.
Does the problem
reoccur?
Replace the staple
cartridge and to go
step 4.
Problem solved.
Step
Questions /
Actions
Yes No
