Lexmark C910 Service Manual

Diagnostic Information 2-35
5055-01X
998 - Tray Elevator Motor Error
6 Check for +24 V
dc between pins 1
and 2 of PJ3 on
the finisher control
board. Is +24 V dc
present?
Replace the finisher
control board.
Replace the power
supply.
Step
Questions /
Actions
Yes No
1 Are the connectors
CN4 at the tray
elevator motor and
connector PJ4 on
the finisher control
board properly
connected?
Go to step 2. Properly connect the
connectors.
2 Make sure that the
finisher set switch is
activated. Power the
printer off. Measure
for approximately
+24 V dc (+ or -10%)
between pins 1 and
2 of connector CN4
at the tray elevator
motor. Power the
printer on and
observe the voltage
meter during the first
12 seconds of power
up. Is +24 V dc
present while the
printer is powering
up?
Replace the tray
elevator motor.
Go to step 3.
Step
Questions /
Actions
Yes No
