1-62 Service Manual
5055-01X
Maintenance Mode
DIP Switch Specifications
The DIP switches on the high capacity paper feed board have the
following functions:
• Function switching and initial setting of the standard machine or
optional machine.
• Maintenance switch (test mode selection) is valid without
connecting to the printer controller board.
DIP
Switch
Function Switch Maintenance Switch
Description
43 2 1
OFF 1 Standard machine
initial setting
ON XX
OFF X 2 Optional machine
initial setting
ON X
DIP
Switch
Function Switch Maintenance Switch
Test paper feed
mode
(standalone)
43 2 1
OFF Test OFF mode
ON XX
OFF X Linear velocity 101
mm/s
Thick paper mode
ON X
OFF XXLinear velocity 129
mm/s
Plain paper mode
ON
OFF X Linear velocity 180
mm/s
ON X
