General Information 1-29
5055-01X
Maintenance Approach
The diagnostic information in this manual leads you to the correct
field replaceable unit (FRU) or part. Use the error code charts,
symptom index, and service checks to determine the symptom and
repair the failure. The removals in the Repair Information chapter
may help you identify parts.
After you complete the repair, perform tests as needed to verify the
repair.
Standard Inspection and Cleaning Procedure
• Switch off Printer power, and disconnect the AC power cord
from the electrical outlet.
• Remove and inspect the photodevelopers and toner cartridges,
shielding them from strong light.
• Inspect the interior of the printer, removing foreign matter such
as paper clips, staples, pieces of paper/transparencies, paper
dust, hair, oil, grease or toner.
• Clean the printer interior using a lint-free cloth, dampened
slightly with cold water. Do not use solvents or chemical
cleaners to clean the printer interior.
• Use only the specified oil or lubricant on printer parts (some
service parts are lubricated at the factory).
Staple Punch
Finisher, 1,100
Sheet (with
stand)
19.5 in.
(495 mm)
20.5 in.
(520 mm)
41.7 in
(1,060
mm)
48.6 lb.
(22 kg)
Furniture
Printer Cabinet 26.6 in.
(675 mm)
23.6 in.
(598 mm)
20.4 in.
(517 mm)
57.5 lb.
(26 kg)
Printer Base 26.6 in.
(675 mm)
21.6 in.
(547 mm)
10.2 in.
(260 mm)
33 lb.
(15 kg)
Note: Weight includes cartridges and supplies.
Width Depth Height Weight
