Page #191 background imageLoading...
Page #191 background image
Diagnostic Information 2-75
5055-01X
Operator Panel Service Check
Paper Carrying Service Check
Paper has not exited or is stopped in the high capacity feeder
(Area F, 249).
• Registration Roller
• Paper Exit Rollers
• Registration Sensor
• Registration Clutch
• Punch Clutch Punch
Unit
• Timing Belt
Run the hole punch test in diagnostic mode
to test the hole punch function.
• Elevator Motor
• Tray Wires
Observe the elevator motor operation while
powering the printer up.
FRU Action
1 • Operator
Panel
• Operator
Panel Cable
• RIP Board
Run both the LCD Hardware Test and the Button
Test in Diagnostic Mode.
Be sure the operator panel cable connections are
securely connected on the RIP board and operator
panel.
FRU Action
1 • Paper Feed
Roller
• Transfer
Roller
Be sure the paper feed roller transfer roller, reverse
roller, and call roller are free of dirt and are not
damaged. Clean or replace parts as necessary.
FRU Action
