Diagnostic Information 2-73
5055-01X
Face Down Stacker Full Service Check
High Capacity Feeder (HCF) Service Check
FRU Action
1 Stacker Full
Detection Lever
Check the stacker full detection lever for damage.
2 Stacker Full
Detection
Sensor
Printer
Controller
Board
Check for a voltage fluctuation between 0 V and +5
V between pins 2 and 3 of connector CN9 on the
printer controller board while actuating the sensor.
FRU Action
1 Paper Size Sensors 1 & 2
Residual Paper Sensors 1 - 4
Paper Level Sensor
Lower Limit Switch
Docking Switch
Upper Limit
Paper Sensor Switch
Paper Feed Sensor
Go to the High Capacity
Paper Feed Sensor / Switch
Test on page 1-64, and
perform the LED sensor test.
You can block each sensor to
verify if it is working properly.
Replace the failing sensor.
2 Tray Motor
Paper Feed Motor
HCPF Power Supply
Pickup Solenoid
Paperfeed Roller
Transfer Roller
Paper Feed Clutch
Tray Drive Belt
Be sure that all rollers, gears,
and belts are in good working
order. Replace as necessary.
3 Paper Feed Clutch
Pickup Solenoid
HCF Power Supply
Paper Feed Motor
Tray Motor
HCPF Board
Go to the Maintenance
Mode on page 1-62 and run
the tests.
