5-16 Service Manual
5055-01X
High Capacity Paper Feed Configuration
H
C
F
Paper feed and separation
mechanism
Tray up & down mechanism
Size detection mechanism
Residual paper detection
mechanism
Paper end detection
mechanism
Friction roller separation system with a non-contact
magnet type maintenance-free torque limiter.
Tray elevating system consisting of a tray motor and
a timing belt.
Fixed to the side fence, and size is entered from
the printer.
Tray level is detected with the fillers and photo
interrupters (4 pieces).
A reflection type sensor on the upper stay detects
the paper.
