Parts Catalog 7-39
5055-01X
Asm-
Index
Part
Number
Units Description
15 - 1 56P9796 1 Roller Assembly, Carrying
2 56P9514 2 Roller, Noise Reduction
3 56P9513 2 Bushing, Carrying
4 56P9509 2 Bushing, Metal
5 56P9790 4 Roller, Paper Carrying
6 56P9792 4 Holder, Roller
7 56P9791 4 Spring, Paper Carrying
8 56P9794 1 Spring, Right Turn Guide
9 56P9789 1 Guide, Turn
10 56P9517 1 Spring, Right Cassette Guide
11 56P9519 1 Guide, Lower Right Cassette
12 56P9516 1 Spring, Left Cassette Guide
13 56P9518 1 Guide, Lower Left Cassette
14 56P9515 1 Guide, Upper Cassette
15 11G0563 1 Interrupter, Photo
16 56P9786 1 Spring, Paper Detection Sensor
17 56P9784 1 Actuator, Paper Detection
18 56P9787 1 Cable, Paper Present Sensor
19 56P9785 1 Cover, Paper Present Sensor
20 56P9788 1 Guide, HCF
21 56P9795 1 Cable, Paper Present Sensor
22 11G0219 1 Interrupter, Photo
23 56P9510 1 Shaft, Paper Feed
24 56P9782 1 Spring, Solenoid
25 56P9783 1 Solenoid, Feeder
26 56P9781 1 Lever, Clutch
27 56P9511 4 Roller Assembly, Paper Feed
28 56P9506 1 Frame, Paper Feed
29 56P9508 1 Bracket, Ground
30 11G0291 1 Clutch, Paper Feed
31 56P9797 1 Cover, Gear
32 11G0297 1 Gear, Paper Carrying
NS 56P9793 1 Spring, Left Turn Guide
NS 56P9507 1 Actuator, Paper Feed Sensor
NS 56P9956 1 Parts Packet
