Parts Catalog 7-43
5055-01X
Asm-
Index
Part
Number
Units Description
17 - 1 56P9825 1 Plate, Paper Re-Feed Drawer
2 56P9827 1 Guide, Rear Side
3 56P9826 1 Guide, Front Side
4 56P9830 1 Solenoid Assembly, Paper Re-feed
5 56P9814 8 Bearing, Release
6 56P9816 2 Spring, Re-feed Roller
7 56P9813 4 Roll, Release
8 56P9525 1 Interrupter Assembly, Photo
9 56P9828 1 Motor Assembly, Paper Guide
10 56P9808 1 Interrupter, Photo
11 56P9526 2 Spring, Feed Roller
12 56P9815 6 Spring, Feed Roller
13 56P9829 3 Solenoid Assembly, Feed Roller
14 56P9831 1 Cable Assembly, Duplex Drawer
15 56P9810 1 Roller, Follow-up Feed
16 56P9527 2 Gear, Idler
17 56P9817 1 Gear, Carrying Roller
18 56P9818 2 Pulley, Carrying Roller Timing
19 56P9819 1 Pulley, Feed Roller
20 56P9822 3 Belt, Timing
21 56P9823 1 Belt, Timing
22 56P9821 1 Knob, Paper Re-feed
23 56P9820 1 Pulley, Re-feed Roller
24 56P9809 1 Roller, Drive Feed
25 56P9824 3 Plate, Paper Carrying Drawer
26 56P9811 3 Roller, Middle Feed
27 56P9812 1 Roller, Re-feed
NS 56P9957 1 Parts Packet
