Parts Catalog 7-59

5055-01X

Asm-

Index

Part

Number

Units Description

25-1 56P9321 2 Spring, I

2 56P9324 1 Cable, Sensor Relay

3 56P9369 12 Assembly, Spring Plate C

4 56P9370 1 Frame, Guide

5 56P9371 1 Spring

6 56P9372 1 Brush, Static Discharge

7 56P9373 2 Screw, M4

8 56P9374 2 Frame, C Guide

9 56P9375 1 Shaft, D

10 56P9376 1 Bushing

11 56P9377 1 Roller, D

12 56P9378 1 Plate, E Spring

13 56P9379 2 Brush, Static Discharge

14 56P9380 1 Sensor, Photo

15 56P9381 1 Frame, B Guide

16 56P9418 1 Guide, Stack

17 56P9399 1 Sensor, Photo

18 56P9382 1 Sensor, Photo

19 56P9383 1 Cushion

20 56P9309 1 Assembly, Exit Guide Inverter

21 56P9302 1 Assembly, Center Guide

22 56P9384 1 Plate, B Spring

23 56P9386 1 Spring

24 56P9387 1 Handle, Jam

25 56P9389 1 Bracket

26 56P9345 1 Cover, Staple Inner B

27 56P9344 1 Cover, Staple Inner A

28 56P9327 1 Cable, Upper Side Panel

Lexmark C910 Service Manual
