Parts Catalog 7-63
5055-01X
Asm-
Index
Part
Number
Units Description
26-1 56P9395 1 Assembly, Guide Plate
2 56P9393 2 Plate, Guide Holder
3 56P9334 1 Assembly, Solenoid
4 56P9396 2 Spring, H
5 56P9397 1 Gear, Z20
6 56P9398 1 Gear, Z19
7 56P9311 4 Bushing
8 56P9310 1 Gate
9 56P9400 1 Roller
10 56P9361 1 Roller, Patting
11 56P9401 1 Roller, I
12 56P9402 1 Bushing
13 56P9403 1 Spring, A
14 56P9404 1 Spring, F
15 56P9312 1 Roller, F
16 56P9405 1 Roller, G
17 56P9335 1 Clutch, Registration
18 56P9338 1 Pulley, T56
19 56P9406 1 Pulley, Z24/T42 Gear
20 56P9407 1 Belt, Timing 60S2M184
21 56P9408 1 Knob
22 56P9339 1 Belt, Timing 60S2M334
23 56P9305 1 Assembly, Tension D
24 56P9411 1 Pulley
25 56P9412 1 Spacer
26 56P9413 1 Assembly, Motor Bracket
27 56P9341 1 Assembly, Feed Motor
28 56P9414 1 Pulley
29 56P9315 1 Assembly, Punch Drive
30 56P9318 1 Spring, B
To Next Page
