Connector Connects to Pin no. Signal
JFUSED Fuser motor 1 HALLF_A_IN
2 HALLF_B_IN
3 HALLF_C_IN
4FG_F_IN
5GND
6+5V_SW
7 V45_FUSER_W
8 V45_FUSER_V
9 V45_FUSER_U
JOUTDC1 Output motor 1 VS10_OUT_LED
2 S_OUT_ENC
3GND
4 V30_OUT_MT-
5 V30_OUT_MT+
JBOR Black only retract 1 VS10_BOR_LED
2S_BOR_ENC
3GND
4 V30_BOR_MT-
5 V30_BOR_MT+
6GND
5028
Component locations
391
