Lexmark CS725R Service Manual

Connector Connects to Pin no. Signal
JLVPS1 LVPS 1 PS_ZERO_X
2PS_HEAT2_ON
3PS_HEAT1_ON
4GND
5 V15_RELAY_DRIVE
6GND
7PS_25V_ON
8GND
9PS_PM_TX
10 PS_PM_RX
11 +6.5V
12 GND
13 +6.5V
14 GND
15 +25V_RAW
16 GND
17 +25V_RAW
18 GND
19 +25V_RAW
20 GND
21 +25V_RAW
22 GND
23 +25V_RAW
24 GND
25 +25V_RAW
26 GND
JCARTP1 CM cartridge motor 1 V45_CM_CART_W
2V45_CM_CART_V
3V45_CM_CART_U
4 V45_Y_CART_W
5V45_Y_CART_V
6 V45_Y_CART_U
5028
Component locations
392
