Page #393 background image
Connector Connects to Pin no. Signal
JCARTS1 Y cartridge motor 1 CM_FG
2CM_HALL_U
3+5V_SW
4CM_HALL_V
5GND
6CM_HALL_W
7GND
8Y_HALL_U
9+5V_SW
10 Y_HALL_V
11 Y_FG
12 Y_HALL_W
JCARTK1 K cartridge motor 1 K_HALL_U
2K_HALL_V
3K_HALL_W
4K_FG
5GND
6+5V_SW
7 V45_K_CART_W
8 V45_K_CART_V
9 V45_K_CART_U
5028
Component locations
393
