Connector Connects to Pin no. Signal
JHVPS1 HVPS 1 +5V_HVPS_REF
2GND
3 M_DEV_PWM_OUT
4 K_DEV_PWM_OUT
5 C_DEV_PWM_OUT
6 CMY_CHG_PWM_OUT
7 Y_DEV_PWM_OUT
8 K_CHG_PWM_OUT
9K_TX_PWM_OUT
10 CMY_TX_PWM_OUT
11 ITM_TX_PWM_OUT
12 GND
13 CMY_SRVO_OUT
14 K_SRVO_OUT
15 ITM_SRVO_OUT
16 GD_HVPS_ID
17 V_25V_HVPS
18 GND
5028
Component locations
394
