Connector Connects to Pin no. Signal
JSC1 Imaging 1 V_FUSE_5V
2I2CDATA_AR_R
3I2CCLK_AR_R
4GND
JBOPT1 Option trays 1 VS45_INOPT_PWR
2GND
3GND
4 S1_OPTION
5RXD_PTR_IN
6 BUMPA_ENC_OPT
7GND
8 TXD_PTR_BTM_OUT
JPSZ1 Paper size sensor 1 PSIZE0
2PSIZE1
3PSIZE2
4PSIZE3
5GND
JMSNS1 MFP paper present sensor, bubble /
narrow media sensors, and duplex
staging sensor
1VS10_MPP
2VS10_MPM
3S_MPP_IN
4GND
5VS10_DSS
6 S_DSS_IN
7GND
8 VS10_BBS
9S_BBS_IN
10 GND
11 VS10_TRAY_NMS
12 S_TRAY_NMS
13 GND
14 GND
JWTH1 Weather station ‑‑ ‑‑
5028
Component locations
