Lexmark CS725R Service Manual

Connector Connects to Pin no. Signal
JWT1 Waste toner 1 SENSE
2WT_VREF
3VAC
4GND
JISP1 ISP connector 1 GND
2USBOUT+
3USBOUT-
4GND
5USB_HD1_D+
6USB_HD1_D-
7GND
8 +3.3V
9 ISP_RST_R
10 +5V_RIP
11 I2C_DAT_ISP_L
12 +5V_RIP
13 I2C_CLK_ISP_L
14 +5V_RIP
J61 Hard drive
JCTM1 TMC 1 +5V_SW
2 -CART_METER_C_IN
3 -CART_METER_M_IN
4 -CART_METER_Y_IN
5 -CART_METER_K_IN
6GND
JSNS1 Bin full / duplex entry sensor
JMIRR1 Mirror motor 1 MM_REF_CLKC
2 MM_LOCK_IN
3 MM_START_OUT
4GND
5 V25_MM_25V
JPFUSB1 USB port
5028
Component locations
398
