Printer hardware errors
111 errors
111 error messages
Error code Description Action
111.00 Pel clock check failed. Go to
“LSU service check” on page 126.
111.01 Downlevel ASIC detected.
111.31 Printhead never delivered HSYNCs.
111.32 Printhead lost HSYNCs.
111.40 Wrong printhead installed
111.50 Open-loop printhead error, open-loop sweep
state.
111.51 Open-loop printhead error, open-loop sweep
state.
111.52 Open-loop printhead error, check prelim amp
state.
111.53 Open-loop printhead error, enable amp Kp state.
111.54 Closed-loop printhead error, amp Kp failed to
converge.
111.55 Closed-loop printhead error while waiting for amp
Kp to converge.
111.56 Closed-loop printhead error, amp Ki failed to
converge.
111.57 Closed-loop printhead error while waiting for amp
Ki to converge.
111.58 Closed-loop printhead error, load scan regs state.
111.59 Closed-loop printhead error, forward and reverse
capture times dier by too much.
4514-2xx
Diagnostics and troubleshooting
125
